Product Details:
|
| Connector: | LC | Rate: | 1.25Gb/s |
|---|---|---|---|
| Diagnostic: | Yes | Commercial Temperature: | 0°C To +70°C |
| Distance: | 2km | Wavelength: | 1310 Nm |
| Power Supply: | 3.3V | Warranty: | 3 Years |
| Product Name: | SFP-1.25G-2D | ||
| Highlight: | SFP Optical Transceiver 2Km 1310nm,1.25 g sfp transceiver 2Km 1310nm,1.25Gbps SFP Optical Transceiver |
||
SFP-1.25G-2D 1.25Gbps SFP Optical Transceiver 2Km 1310nm Fibre Module
SFP-1.25G-2D Features:
1310nm FP(LED)laser and PIN photo detector for 2km transmission with MMF
Up to 1.25Gbps data rate operationl Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitor Interface
Very low EMI and excellent ESD protection
+3.3V single power supply
RoHS compliant
Case operating temperature Commercial: 0°C to +70°C Extended: -10°C to +80°C Industrial: -40°C to +85°C
Applications of SFP-1.25G-2D:
SDH STM-1, I-1
Sonet OC-3,SR1
Fast Ethernet
Other optical transmission systems
Description of SFP-1.25G-2D
The SFP transceivers are high performance, cost effective modules supporting 1.25Gbps data-rate and 2km transmission distance with MMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
1310nm 2KM SFP Optical Module Specification of SFP-1.25G-2D
| Digital Diagnostic Monitor | Yes |
|
Extended temperture |
-10°C to +80°C |
| Certificate | CE |
|
Supply Voltage |
3.3V |
| Gross weight | 0.035/kg |
| Carton Size | 22cmx17cmx7cm |
| Warranty | 3 years |
| Packing | 10pcs /box |
|
Wavelength Range |
1310nm |
|
TX Power |
-8 to 1 |
