Single Mode Fiber 100G QSFP28 CWDM4 2KM Ciena Small Form Factor Pluggable Modules

Single Mode Fiber 100G QSFP28 CWDM4 2KM Transceiver Ciena Small Form-Factor Pluggable Modules

Ciena® 160-9403-900 QSFP28 100G  Product Features

Feature:

Ciena Compatible 160-9403-900 Features:

Hot pluggable QSFP28 MSA form factor

Supports 103 Gbps

Up to 2km reach for G.652 SMF

Single +3.3V power supply

Transmitter: cooled 4x25 Gbps CWDM ML TOSA (1270, 1290, 1310, 1330nm)

Receiver: 4x25 Gbps PIN ROSA

4x25G Electrical Serial Interface

Maximum power consumption 3.5W

RoHS-6 compliant (lead-free)

Duplex LC receptacle

12C interface with integrated Digital Diagnostic Monitoring

Operating Case Temperature

Standard

O to +70 °C

Extended

-4 to +85 °C

Industrial

-40 to +85 °C

Ciena Compatible 160-9403-900 Overview

The 160-9403-900 is a 103 bps transceiver module designed for optical communication applications compliant to

100GBASE-CWDM4 of the IEEE P802.3ba standard. The module converts 4 input channels of 25 Gps electrical data to 4

optical CWDM channels and then multiplexes them into a single channel for 103 Gbps optical transmission. Reversely on

the receiver side, the module de-multiplexes a 103 Gbps optical input into 4 channels of CWDM optical signals and then

converts them to 4 output channels of electrical data. The central wavelengths of the 4 LAN WDM channels are 1270,

1290, 1310 and 1330 nm as members of the CWDM wavelength grid. The high performance cooled ML DFB

transmitters and high sensitivity PIN receivers provide superior performance for 100G applications up to 2km links. The

product is designed with form factor, optical/electrical connection and digital diagnostic interface per the QSFP+ Multi-source Agreement.

QSFP28 100G  Description

FAQ

Q1. Are your Optical Transceivers original?

A1.Yes, all our optical transceivers are guaranteed 100% original!

Q2.How do you guarantee the quality of optical module ?

A2.There are professional testing equipments and QC team. Every unit will be fully tested with perfect performance before shipping.

Q3. What will you do if I found the product has any quality problem?

A3.We back up every sale with our risk-free money-back guarantee! You can buy with confidence from a company in good faith that has been serving its clients for over 10 years! Our dream is to build a famous 100 years enterprise!

Q4. What are the trade terms?

A4.Lead Time: 1-3 day after confirm your payment (In stock, we need 1 day to fully test them)

Payment term: Western Union, T/T, Alipay, Escow, Money Gram

Warranty: 1 Year

Q5. Do you have compatible ones?

A5.Yes, we have our own brand:Top-trans, including 1X9,SFP, XFP, SFP+, BIDI in all kinds of specifications.
