Product Details:
|
| Rate: | 10G | Form Factor: | XFP |
|---|---|---|---|
| Wavelength: | 1310 Nm | Temperature Range: | 0 To 70°C |
| Application: | Data Center | Connector Type: | Duplex LC |
| Temperature Range:: | 0 To +70 °C | Media Type: | Single Modules |
| Reach: | 10Km | Warranty: | 1 Year |
| Highlight: | Cisco Xfp 10g Single Modules,1310Nm Transceivers Optical Modules |
||
ONS-XC-10G-S1 XFP 10G Single Modules 10KM Optical Moduels 1310 Nm Transceivers
Feature ONS-XC-10G-S1 :
Support multi protocol from 9.95Gb/s to 11.3Gb/s
Hot pluggable 30 pin connector
Compliant with XFP MSA
Transmission distance of 10km over Single mode fiber
1310nm DFB laser transmitter
Duplex LC connector
2-wire interface for management and diagnostic monitor
XFI electrical interface with AC coupling
Single power supply voltages : +3.3V
Temperature range: 0°C to 70°C
Power dissipation: <1.5W
RoHS compliant
Application :
10GBASE-LR/LW Ethernet
SONET OC-192/SDH STM-64
1200-SM-LL-L 10G Fiber Channel
Other Optical Links
| Rate | 10G |
| Wavelength | 1310 nm |
| DDM | yes |
| Form Factor | XFP |
| temperature range | 0 to 70°C |
| Connector | Duplex LC |
| Media Type | Single Mode Fiber |
The XFP-10GLR-31 Small Form Factor 10Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA)
Specification. They comply with 10-Gigabit Ethernet 10GBASE-LR/LW per IEEE 802.3ae and 10G Fibre Channel 1200-SM-LL-L. Digital
diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.
