Product Details:
|
| Center Wavelength: | 1304.5 Nm To 1317.5 Nm | Temperature: | 0°C~+70°C |
|---|---|---|---|
| Weight: | 0.05KG/PCS | Performance: | Auto-sensing Of 64G, 32G, And 16G Port Speeds. |
| Cable Type: | SMF | Cable Distance: | 10km |
| Connector: | Industry-standard LC Duplex | Compliant: | RoHS |
| Highlight: | 64G Fibre Channel SFP+ Transceiver,SFP+ Transceiver For X7 Director |
||
Brocade 57-1000496-01 XBR-000468 64G Fibre Channel SFP+ Transceiver LWL 10km for X7 Director
Brocade 64G FC SFP+ LW Transceiver Specification
The Brocade® 64G long wavelength (LWL) SFP+, part of the Brocade family of optical transceivers, is optimized for Brocade 64G director and switch products. Together, these optical transceivers provide state-of-the-art performance, while extending data center connectivity (up to) a distance of 10 km. This optical transceiver operates over single-mode fiber and uses an industry-standard LC connector.
Diagnostic features of the Brocade 64G LWL SFP+ optical transceiver comply with SFF-8472 Rev. 12.3, providing real-time monitoring of the following:
• Transmitted optical power
• Received optical power
• Laser bias current
• Temperature
• Supply voltage
• Power-on hours
Highlights
• Provides extended Fibre Channel connectivity over long distance.
• Operates over duplex single-mode fiber.
• Uses an industry-standard singlemode LC connector.
• Supports a link length of up to 10 km over single-mode fiber.
• IEC 60825-1 Class 1/CDRH Class 1 laser, eye-safe. • RoHS 6 compl
Ordering Part Number
• XBR-000468 (1-pack)
• XBR-000469 (8-pack)
Parameters for the 64Gb/s LW FC SFP Transceiver Module:
| Performance | Fibre Channel: 57.8Gb/s, 28.05Gb/s, and 14.025Gb/s line speed, full duplex; |
| Media | Hot-pluggable, industry-standard small form-factor pluggable (SFP+), LC connector; LWL 10 km. This transceiver is targeted for long-reach applications with high-power transmitters. Attenuation of ~6 dB is needed for loopback testing. |
| Operating Parameters |
Transmit (Tx): Wavelength: 1304.5 nm to 1317.5 nm Average power: –4.5 dBm to +4.2 dBm RIN: −134 dB/Hz max OMA: –1.5 dBm min, +4 dBm max Receive (Rx): Average power: +4.2 dBm max Optical return loss: –26 dB max Unstressed sensitivity: –8.9 dBm min |
| Size |
Width: 14.80 mm (0.58 inches) Height: 12.21 mm (0.48 inches) Depth: 56.70 mm (2.23 inches) |
| Storage Temperature | −40°C to +85°C (−40°F to +185°F) |
| Power Dissipation | 2.0W |
Photo for Brocade 64Gb/s 10km FC SFP+ Transceiver
FAQ
Q1. Except for this Brocade 64Gb/s 10km FC SFP+ Transceiver optical modules, what else Brocade sfp can you offer?
A1: pls check the below form for the Brocade optical module we can offer;
| Data Rate |
Description
|
Manufacturing
Part Number
|
Brocade Ordering
Part Number
|
|
4x32G FC QSFP+
|
SWL
|
57-1000351-01
|
XBR-000275 (1-pack)
|
| 4x32G FC QSFP+ |
SWL
|
57-1000490-01
|
XBR-000475 (1-pack)
|
| 4x32G FC QSFP+ |
2 km
|
57-1000480-01
|
XBR-000285 (1-pack)
|
| 64G FC SFP+ |
SWL
|
57-1000495-01
|
XBR-000462 (1-pack)
XBR-000463 (8-pack)
|
| 64G FC SFP+ |
LWL - 10 km
|
57-1000496-01
|
XBR-000468 (1-pack)
XBR-000469 (8-pack)
|
| 64G FC SFP+ |
ELWL - 25 km
|
57-1000497-01
|
XBR-000466 (1-pack)
|
|
32G FC SFP+
|
SWL
|
57-1000333-01
|
XBR-000212 (1-pack)
XBR-000213 (8-pack)
|
| 32G FC SFP+ |
SWL
|
57-1000485-01
|
XBR-000412 (1-pack)
XBR-000413 (8-pack)
|
| 32G FC SFP+ |
LWL - 10 km
|
57-1000332-01
|
XBR-000238 (1-pack)
XBR-000239 (8-pack)
|
| 32G FC SFP+ |
LWL - 10 km
|
57-1000486-01
|
XBR-000438 (1-pack)
XBR-000439 (8-pack)
|
| 32G FC SFP+ |
ELWL - 25 km
|
57-1000355-01
|
XBR-000278 (1-pack)
|
| 32G FC SFP+ |
ELWL - 25 km
|
57-1000494-01
|
XBR-000478 (1-pack)
|
| 32G FC SFP+ |
ELWL - 25 km
|
57-1000498-01
|
XBR-000479 (1-pack)
|
|
16G FC SFP+
|
SWL
|
57-0000088-01
|
XBR-000192 (1-pack)
XBR-000193 (8-pack)
|
|
16G FC SFP+
|
SWL
|
57-1000487-01
|
XBR-000492 (1-pack)
XBR-000493 (8-pack)
|
|
16G FC SFP+
|
LWL - 10 km |
57-0000089-01
|
XBR-000198 (1-pack)
XBR-000199 (8-pack)
|
|
16G FC SFP+
|
LWL - 10 km |
57-1000488-01
|
XBR-000498 (1-pack)
XBR-000499 (8-pack)
|
|
16G FC SFP+
|
ELWL - 25 km |
57-1000262-01
|
XBR-000258 (1-pack)
|
|
16G FC SFP+
|
ELWL - 25 km |
57-1000489-01
|
XBR-000458 (1-pack)
|
|
8G FC SFP+
|
SWL
|
57-1000117-01
|
XBR-000163 (1-pack)
XBR-000164 (8-pack)
|
| 8G FC SFP+ | LWL - 10 km |
57-1000027-02
|
XBR-000153 (1-pack)
XBR-000172 (8-pack)
|
| 8G FC SFP+ | ELWL - 25 km |
57-0000080-01
|
XBR-000174 (1-pack)
|
Q2:Is this genuine Brocade Original 4x16G 100M FC SFP Transceiver?
A2:Yes, Topstar is the top lead Brocade distributor in China, we sell the brand SFP since year 2006 and never sell fake or copy brand items.
Q3:Does your SFP provide a quality warranty?
A3:For brocade SFP, we offer 1-year warranty. Any quality problem, we will replace for you;
Q4:Can you send this SFP module to my place? and how long does it take?
A4:Yes, we can provide door to door shipment via DHL, FEDEX, Aramex and UPS etc logistic services.
The express logistic generally takes 5-12 days to global.
