Product Details:
|
| Rate: | 10G | Wavelength: | 1550nm |
|---|---|---|---|
| Reach: | 80KM | Connector Type: | Dual LC |
| Extinction Ratio: | 10dB | Cable Type: | Single Mode Fiber |
| Form Factor: | SFP+ | Temperature: | 0 To 70°C |
| Highlight: | Cisco SFP Module Single Mode,Cisco SFP-10G-ZR,Dual Connector Optical Modules |
||
Cisco SFP-10G-ZR Singe Mode Fiber Channel SFP+10 Gigabit Ethernet Dual Connector Optical Modules
Product specifications
Product Number: SFP-10G-ZR
Description: Cisco multirate 10GBASE-ZR, 10GBASE-ZW and OTU2e SFP+ Module for SMF
Connectors: Dual LC/PC connector
Wavelength: 1550nm
Cable Type: SMF
Cable Distance: 80km
Transmit Power (dBm):
Maximum: 4.0
Minimum: 0
Receive Power (dBm):
Maximum: -7
Minimum: -24
Transmit and Receive Wavelength: 1530 to 1565nm
Bail Latch Color: Green
Power Consumption: 1.5W
Operating Temperature Range: Commercial temperature range (COM): 0 to 70°C (32 to 158°F)
Storage temperature range: -40 to 85°C (-40 to 185°F)
| Rate | 10G |
| Connection Type | Dual -LC |
| Maximum Transfer Distance | 1550 nm |
| Reach | 80KM |
| Media type | Single mode Fiber |
| temperature range | 0°C ~ 70°C |
| Form factor | SFP+ |
| Power Consumption | 1.5W |
