Product Details:
|
| Form-Factor: | QSFP56 FR4 | Data Rate: | 200G |
|---|---|---|---|
| Center Wavelength: | 1310nm | Transmission Distance: | 2km |
| Temperature: | 0C~+70C | OEM Or ODM: | Support |
| Weight: | 0.06KG Per Piece | Warranty: | 3 Years |
Original Accelink RTXM500-301 200G QSFP56 SR4 100m Optical Transceiver
RTXM500-301 200G QSFP56 SR4 transceiver modules are designed for use in 200 Gigabit Ethernet links on up to 100m of Multimode fiber. They are compliant with the QSFP MSA and IEEE 802.3cd.The optical transceiver is RoHS compliant.The product supports immersion liquid cooling applications
Parameters
| Fiber Type | MMF |
| Connector | MPO-12 |
| Lasers and TIA | EML APD |
| Tx Power | 0.4 to 6.5 dBm |
| Rx Sensitivity | -29 to -15.1 dBm |
| Extinction Ratio | 6 dB |
| Power Consumption | <5 W |
| Multi Power Supply | 3.3 V |
PRODUCT FEATURES
IEEE802.3bs 200GBASE-FR4 compliant
• QSFP56 and CMIS MSA compliant
• 4 CWDM lanes MUX/DEMUX design
• Supports 212.5Gb/s aggregate bit rate
• Up to 2km transmission on single mode fiber (SMF) with FEC
• Operating case temperature: 10 to 60oC
• 200GAUI-4 electrical interface
• Maximum power consumption 6.5W
• LC duplex connector
• RoHS compliant
FAQ
Q1. Are your transceiver modules compatible with Cisco?
A1: Yes, Topstar transceivers can compatible with Cisco. All the brand Topstar's SFP compatible as the fellowing:Cisco, Nortel, Juniper, 3COM, H3C, Alcatel-lucent, FOUNDRY, D-Link, EXTREME, Ruijie, NETGEAR, ZTE, Enterasys, ZyXEL, Linksys, Ericsson, DCN, Allied, SMC, Brocade, Force10, Hirschmann, Planet, Adtran, ASNTE, Trendnet, BDCOM, BLADE, BITWAY, Telco, Feixun...etc.
Q2. How does your company do regarding quality control?
A2: Every single optic individually tested in our test center , and also tested for compatibility on a variety of different brands of network equipment.
Q3. What are the trade terms?
A3: Lead Time: we keep 40,000pcs SFP in stock ready to ship.
Payment term: T/T, Western Union, Alipay, Paypal, L/C and so on for your option.
Q4. What is operating temperature range of optical modules?
A4: Commercial temperature range(COM) : 0 to 70°C(32 to 158°F)
Storage temperature range:-40 to +85°C(-40 to 185°F)
We can supply according to your request.
