Product Details:
|
| Form-Factor: | QSFP56 | Data Rate: | 200G |
|---|---|---|---|
| Center Wavelength: | 1310nm | Transmission Distance: | 500m |
| Temperature: | 0C~+70C | OEM Or ODM: | Support |
| Weight: | 0.06KG Per Piece | Warranty: | 3 Years |
| Highlight: | 200GBASE-FR4 QSFP56 Optical Transceiver,500m QSFP56 Optical Transceiver,CWDM EML Optical Module |
||
200GBASE-FR4 500m QSFP56 Optical Transceiver FTCC1122E2PCL CWDM EML Optical Module Original
On 200G QSFP-DD PAM4 is enabled by DSP (digital signal processor) that acts like a gear box to convert 8 electrical signal channels to 4 optical signal channels. Electrical signal interface can be 25 Gbps NRZ or 50 Gbps PAM4 and after passing through DSP Transceiver Optical signal is 25Gbps PAM4 and 50 Gbps PAM4 respectively. Thus, 200G QSFP-DD transceivers can have 8 x 25 Gbps or 4 x 50 Gbps optical channels. The number of optical channels is shown at the end of Industry Name and is different per module type. For example, 400GBASE-SR8 has 8x 50 Gbps PAM4 optical transmission channels.
Parameters
| Fiber Type | SMF |
| Connector | LC |
| Lasers and TIA | EML APD |
| Tx Power | 0.4 to 6.5 dBm |
| Rx Sensitivity | -29 to -15.1 dBm |
| Extinction Ratio | 6 dB |
| Power Consumption | <10 W |
| Single Power Supply | 3.3 V |
PRODUCT FEATURES
FAQ
Q1. Are your transceiver modules compatible with Cisco?
A1: Yes, Topstar transceivers can compatible with Cisco. All the brand Topstar's SFP compatible as the fellowing:Cisco, Nortel, Juniper, 3COM, H3C, Alcatel-lucent, FOUNDRY, D-Link, EXTREME, Ruijie, NETGEAR, ZTE, Enterasys, ZyXEL, Linksys, Ericsson, DCN, Allied, SMC, Brocade, Force10, Hirschmann, Planet, Adtran, ASNTE, Trendnet, BDCOM, BLADE, BITWAY, Telco, Feixun...etc.
Q2. How does your company do regarding quality control?
A2: Every single optic individually tested in our test center , and also tested for compatibility on a variety of different brands of network equipment.
Q3. What are the trade terms?
A3: Lead Time: we keep 40,000pcs SFP in stock ready to ship.
Payment term: T/T, Western Union, Alipay, Paypal, L/C and so on for your option.
Q4. What is operating temperature range of optical modules?
A4: Commercial temperature range(COM) : 0 to 70°C(32 to 158°F)
Storage temperature range:-40 to +85°C(-40 to 185°F)
We can supply according to your request.
