Product Details:
|
| Data Rate: | QSFP-100G-SWDM4 | Form-Factor: | QSFP-100G-SWDM4 Optical Transceiver |
|---|---|---|---|
| Center Wavelength: | SWDM4 | Transmission Distance: | 100m |
| Temperature: | 0°C To 70°C | Connector: | Duplex LC Receptacles |
| Weight: | 0.34g | Warranty: | 1 Years |
Compatible QSFP-100G-SWDM4 100m Fiber Optic Sfp Module Duplex LC MMF
Parameters
| Fiber Type |
100G Ethernet |
| Connector | Duplex LC receptacles |
| Lasers and TIA | VCSEL and PIN |
| Tx Power | -5~-1 dBm |
| Rx Sensitivity | -12 dBm |
| Extinction Ratio | 5.5 dB |
| Power Consumption | 1W |
| Single Power Supply | 3.3 V |
Product Description: Arista QSFP-100G-SWDM4 Optical Module
Key Features:
Form Factor: The Arista QSFP-100G-SWDM4 XVR-10167-20 optical module is designed in the QSFP28 form factor, which is a compact and hot-pluggable interface widely used in data center networking equipment.
Data Rate: It supports a high data rate of 100 Gbps, making it suitable for demanding data center and enterprise applications.
Wavelength: The module operates on Short Wavelength Division Multiplexing (SWDM4) technology, using four different wavelengths (850 nm) over a single multimode fiber.
Connector: It features MTP/MPO connectors, which are commonly used for high-speed optical connections in data center environments.
Transmission Distance: The QSFP-100G-SWDM4 is optimized for short-range connections, with a typical reach of up to 150 meters over OM4 multimode fiber.
Digital Diagnostics (DDM): The module includes digital diagnostics functionality, allowing for real-time monitoring of critical parameters such as optical power, temperature, and voltage.
Hot-Pluggable: It supports hot-pluggable functionality, enabling easy installation and replacement without disrupting network operations.
Low Power Consumption: This optical module is designed for energy efficiency, with low power consumption to reduce operational costs.
Compliance: The QSFP-100G-SWDM4 is compliant with industry standards and specifications, ensuring compatibility with a wide range of networking equipment.
Applications:
The Arista QSFP-100G-SWDM4 XVR-10167-20 optical module is suitable for various applications, including:
Data Center Connectivity: It can be used for high-speed data transmission within data centers, connecting switches, routers, and servers.
Ethernet Networking: The module is compatible with Ethernet networks and can be used for short-range Ethernet connections.
Storage Area Networks (SANs): It is suitable for use in SAN environments where high-speed data transfer is required.
Telecommunications: The module can also be used in telecommunications networks for short-distance optical connections.
FAQ OF SFP+
1. Are your Optical Transceivers original?
Yes, all our optical transceivers are guaranteed 100% original!
2. What will you do if I found the product has any quality problem?
We back up every sale with our risk-free money-back guarantee! You can buy with confidence from a company in good faith that has been serving its clients for over 10 years!
3. What did your company do in terms of quality control?
We have professional testing equipment and QC team. Every unit will be fully tested with perfect performance before shipping.
4. What are the trade terms?
Lead Time: 1 day after confirm your payment (In stock, we need 1 day to fully test them)
Payment term: Western Union, T/T, Aliexpress Escow, Money Gram
Warranty: 1 Year
5. Do you have compatible ones?
Yes, we have our own brand—Toptrans, including SFP, XFP, SFP+, Bidi in all kinds of specifications.
